20inch Carbon Rim and Wheel

Overview

This rim is Tubeless, not need a tube, if use a tube also possible.

we optimizing the rim structure, make it stronger, also have a good aero.

The rim design in different weight, the heavier rim will much stronger.

If for child bike use, suggest 300g and 320g is enough.

If for BMX race use, suggest front wheel 320g, rear wheel 340g, or both 340g.

If for BMX Game use, suggest 360g or 380g.

The rim can be used for Bmx, Bmx race, Child Bike, 20" MTB, Folding bike, Recumbent bike, eco car etc.

Please tell us where you will use this rim before order, then we will recommend a fit weight.

1. Spokes holes can be customized, eg G3, SAT etc
2. Worldwide shipping, Lead time: 5-7 days.
3. 2 year warranty, any quality defects replace for free.

Please feel free to contact us for more details.

Specs

Size: 20" 406 Use: BMX or 20" MTB
Model: 406-C2 Brake: Rim brake or Disc brake
Type: Tubeless Weight: 320+/-10g
Width: 30mm Depth: 25MM
ERD: 375mm Material: full carbon Toray T700
Weave: UD/3K/12K/18K Finish: Matte/Glossy
Holes: 16H to 32H Drilling: average or customized
Tire width: 40 to 54 compatible Tire pressure: Can reference tyre
Warranty: Lifetime warranty Standard: En standard
Lead time 10-15 days Valve: Presta or Schrader


Contact us


Contact Form













Overview

This rim design for BMX, BMX race,  it's rim wide 30mm.

we optimizing the rim structure, make it stronger, also have a good aero.

The rim design in different weight, the heavier rim will much stronger.

If for child bike use, suggest 300g and 320g is enough.

If for BMX race use, suggest front wheel 320g, rear wheel 340g, or both 340g.

If for BMX Game use, suggest 360g or 380g.

The rim can be used for Bmx, Bmx race, Child Bike, 20" MTB, Folding bike, Recumbent bike, eco car etc.

Please tell us where you will use this rim before order, then we will recommend a fit weight.

1. Spokes holes can be customized, eg G3, SAT etc
2. Worldwide shipping, Lead time: 5-7 days.
3. 2 year warranty, any quality defects replace for free.

Please feel free to contact us for more details.

Specs

Size: 20" 406 Use: BMX or 20" MTB
Model: 406-C3 Brake: Rim brake or Disc brake
Type: Clincher Weight: 340+/-10g
Width: 30mm Depth: 30MM
ERD: 365mm Material: full carbon Toray T700
Weave: UD/3K/12K/18K Finish: Matte/Glossy
Holes: 16H to 32H Drilling: average or customized
Tire width: 40 to 54 compatible Tire pressure: Can reference tyre
Warranty: Lifetime warranty Standard: En standard
Lead time 5-7 days Valve: Presta or Schrader


Contact us


Contact Form













Overview

The rim structure was designed to be wide U-Shape, its wide 25mm, which make it stronger, looks more beautiful and have a good aero.

Rim Surface use thermal conductivity nano materials Graphenel, its thermal conductivity is>500W/m*k, brake heat can disperse effectively.

The rim can be used for Birdy bike, Moulton bicycle, Dahon, Tern bike, Tyrell, Fsir, Folding bike, Recumbent bike, BMX, BMX Race, ECO Car etc.

1. Spokes holes can be customized, eg G3, SAT etc
2. Worldwide shipping, Lead time: 5-7 days.
3. Lifetime warranty, any quality defects replace for free.

Please feel free to contact us for more details.

Specs

Size: 20" 406 Use: Folding / recumbent bike or others
Model: 406-C1 Brake: Rim brake or Disc brake
Type: Clincher Weight: 320+/-10g
Width: 25mm Depth: 50MM
ERD: 325mm Material: full carbon Toray T700
Weave: UD/3K/12K/18K Finish: Matte/Glossy
Holes: 16H to 36H Drilling: average or customized
Tire width: 23 to 37 compatible Tire pressure: Max 120 psi
Warranty: Lifetime warranty Standard: En standard
Lead time 5-7 days Valve: Presta or Schrader


Contact us


Contact Form













Overview

This is a lightweigt carbon wheelset design for 20" Birdy bike Disc brake.

The wheelset use Blade spokes to let bike have better aero.

The rim structure was designed to be U-Shape, which make it stronger, looks more beautiful and have a good aero.

Rim Surface use thermal conductivity nano materials Graphenel, its thermal conductivity is>500W/m*k, brake heat can disperse effectively.

1. Minimum order quantity(MOQ): 1 set
2. Wheelset including quick release (skewers).
3. Worldwide shipping, Lead time: 5-10 days.
4. Lifetime warranty, any quality defects replace for free.

Please feel free to contact us for more details.

Specs

Wheel Size: 20" 406 Use: 20" Birdy Disc brake
Wheel model: 406-BD1 Brake: Disc brake
Wheel weight: 1130+/-20g Hub weight: 350g
Hub O.L.D.:  100mm/135mm Hub color: Black
Nipple color: Black/Red/Sliver Spokes: Sapim or Pillar Bladed (Black)
Rim Type: Clincher Rim weight: 320+/-10g
Rim Width: 25mm Rim Depth: 50MM
Rim ERD: 325mm Rim Material: full carbon Toray T700
Rim Weave: UD/3K/12K/18K Rim Finish: Matte/Glossy
Rim Holes: 24H/24H or 28H/28H Rim Drilling: average holes or G2/G3
Tire width: 23 to 37 compatible Tire pressure: Max 120 psi
Rim warranty: Lifetime warranty Standard: En standard
Lead time 5-10 days Valve: Presta or Schrader


Contact us


Contact Form













Overview

This is a lightweigt carbon wheelset design for 20" Birdy bike V brake.

The wheelset use Blade spokes to let bike have better aero.

The rim structure was designed to be U-Shape, which make it stronger, looks more beautiful and have a good aero.

Rim Surface use thermal conductivity nano materials Graphenel, its thermal conductivity is>500W/m*k, brake heat can disperse effectively.

The wheelset can be used for Birdy bike V brake.

1. Minimum order quantity(MOQ): 1 set
2. Wheelset including quick release (skewers).
3. Worldwide shipping, Lead time: 5-10 days.
4. Lifetime warranty, any quality defects replace for free.

Please feel free to contact us for more details.

Specs

Wheel Size: 20" 406 Use: 20" Birdy V brake
Wheel model: 406-BD2 Brake: Rim brake
Wheel weight: 1060+/-20g Hub weight: 280g
Hub O.L.D.:  100mm/135mm Hub color: Black
Nipple color: Black/Red/Sliver Spokes: Sapim or Pillar Bladed (Black)
Rim Type: Clincher Rim weight: 320+/-10g
Rim Width: 25mm Rim Depth: 50MM
Rim ERD: 325mm Rim Material: full carbon Toray T700
Rim Weave: UD/3K/12K/18K Rim Finish: Matte/Glossy
Rim Holes: 20H/24H Rim Drilling: average holes or G2/G3
Tire width: 23 to 37 compatible Tire pressure: Max 120 psi
Rim warranty: Lifetime warranty Standard: En standard
Lead time 5-10 days Valve: Presta or Schrader
